Description
SPECIFICATIONS
Brand Name: SHOJZJ
SHOJZJ Model: TY-BAC003
Origin: Mainland China
Wattage: <1.5W
Certification: CE
Certification: FCC
Certification: RoHS
Model Number: OJ-03
Voltage: 95V-240V, 50/60HZ
Voltage 2: 1-10V
Voltage 3: 24V
Fan Relay Amps Resistance: 5A
Inductve: 3A
Valve Relay Amps Resistance: 3A
Sensor: NTC3950 10K
Set Temp. Range: :5 -35 ℃
Accuracy: ±0.5 ℃
Dispaly Temp. Range: 5c-99c
Control mode: Mobile APP, remote control,
APP: TUYA
APP2: SMART LIFE
Working with 1: Alexa
Working with 2: Google
Protecton Class: IP20
Buttons: Capactve Touch Buttons
TUYA Smart Thermostat Wifi for Central Air Conditioner 24V 0~10V Valve Temperature 3 Speed Fan External sensor Wireless Controller Support replacement Honeywell for Alice, Alexa，google
smart thermostat
Thermostat can control heating/cooling elements to adjust user room temperature, in order to creat a comfortable home. You can set any temperature in which they want. SMART HOME WIFI thermostat can be controlled by Mobile Phone, so user can use phone as a remote controller, to control room heating/cooling anywhere and anytime. Thermostats are designed to on/off control the fans and valves in air conditioner ,applications via comparison of the room temperature and setting temp, as reaching the aim of comfort and saving energy.
Features:
A: Two pipe; Control Fan Coil Unit and Two Wired Motorized Valve
M : Two pipe; Control Fan Coil Unit and 0-10V Motorized Valve
E : Four pipe; Control Fan Coil Unit and Two Wired Heat Valve and
Two Wired Cool Valve.
N : Modbus RTU communication B:BACnet communication
W : Wifi connection
K: Keycard
W2 : Window
E : External Sensor
1. Powerful functions are available such as Modbus/WIFI etc,.
2. 0.5°C Accuracy keeps temperature within the level you set.
3. Clock memory when power is off.
4. 5+2 six periods programmable maximize comfort and economy.
5. Create thermostat group to centrally control.
6. Integrated with Amazon Echo, Google Home, .
7. Support Device Sharing to your family or friends.
8. All setting languages synchronize your time zone, address and language
9. No limit to add thermostats in App.
10. Support Smart Scene, Protection Class: IP20.
BEFORE WIRING AND INSTALLING...
1. Read these instructions carefully. Failure to follow them could damage the product or cause a hazardous condition.
2. Check the ratings given in the instructions and on the product to make sure the product is suitable for your application.
3. Installer must be a trained, experienced service technician
4. After installation is complete, check out product operation as provided in these instructions.
Ntegrated with Amazon Echo, Google Home,
sleek, contemporary design.
temperature control throughout every room in your property. We
bring together technology, craftsmanship and the highest quality
Heating and Cooling Temperature 3 Speed Fan Coil Unit
are designed to on/off control the fans and valves in air conditioner
WiFi Tuya Central Air Conditioner Thermostat
perfectly integrated into your family.
applications via comparison of the room temperature and setting
Powerful functons are available
No limit to add thermostats in App and support Smart Scene
Integrate with Amazon Echo, Google Home,
Support device sharing.
Child Lock
Prevent children from touching by mistake and avoid unnecessary losses
Locking your Thermostat
Press and hold the for 5 seconds to lock/unlock your thermostat.
Powerful functions
5+2 six periods programmable maximize comfort and economy
Temporary programmable
All setng languages sunchronize your �me zone, address andlanguage.
℃ or ℉ can be customized.
Product Show
WIRING
PRODUCT SIZE
INSTALLATION
Your thermostat is suitable for installation within a standard 86mm
pattress box or European 60mm pattress box.
Step 1. Keep the electricity off. See Fig 1.
Step 2. Remove the mounting Plate by rotating the LCD part. See Fig 2. .
Step 3. Connect power supply, load into the appropriate terminals.(see "Wiring your thermostat" for details and Fig 3).
Step 4. Fix the mounting plate into the wall with screws in the box. See Fig 4.
Step 6. Installation complete. See Fig 6.
certificate
